Instant Gas Hot Water Systems

Also known as continuous flow gas hot water systems, these will provide you with an endless supply of hot water so you never have to worry about running out of hot water again.Bosch-Condensing-Hot-Water-System-26eco+

This style of hot water system is the most economical to run and some other noteworthy features are

  1. No need to keep a large tank of water hot all day and night
  2. No pilot light
  3. No servicing required
  4. Long warranty,- 3 years parts and labour, 10 years on heat exhanger
  5. Temperature can be set either at the appiance or from a control pad inside the house
  6. Endless hot water
  7. 5 star rated/energy efficient
  8. Compact size, about the size of a briefcase
  9. Anti frost models
  10. Solar compatible models
  11. Bathfill option will turn the water off when desired volume has been reached
  12. Highest quality manufactured

Instant gas hot water systems will provide you with a system to suit you and your family’s hot water needs providing you with a system that will last for years past it’s warranty. SA Hot Water™ are plumbers in Adelaide specialising in all brands and types of hot water systems.

Bosch Hot Water Systems

SA Hot Water™ sells the complete range of Bosch Hot water systems at the best prices in Adelaide.

We also supply the full range of Bosch Spare Parts

Bosch manufacture the following types of systems:

Bosch Optiflow Bluetooth
Bosch Optiflow

Bosch Optiflow Bluetooth

OptiFlow combustion management system
Bluetooth enabled appliance (up to 10m range)
Compatible with Water & ProWater Apps
6 star efficiency
Compact, lightweight
Solar compatible water heater
Electronically controlled modulation
Up to 3 controllers can be installed in addition to the Bluetooth controller
50°C compliant models available

Bosch has redefined hot water systems with the Bosch OptiFlow, the first water heater with Bluetooth connectivity on the Australian market.

Models are available in 16, 20 and 26 litre per minute flow rates.

Bluetooth connectivity offers several benefits. A free app for users allows them to track usage statistics, as well as serving as an additional thermostat, while a free app for plumbers allows them to remotely adjust settings and run diagnostics, making installation more time- and cost-effective. In addition to its Bluetooth connectivity, the OptiFlow also utilises the patented Bosch OptiFlow algorithm, which continuously adapts the system’s gas-air ratio throughout its lifetime, ensuring optimum performance and effectiveness. This water heater also utilises Bosch’s patented “Easy Minimum” technology for maximum comfort, and its elegant design makes it a true architectural feature.

Bosch Water App for the User
– Temperature control
– Running cost information
– Energy usage information
– Water consumption information

Play Store

App Store

The Bosch OptiFlow with Bluetooth is gas-powered, 6 star continuous flow hot water system which comes in 16L, 20L and 26L varieties. Bosch is bringing hot water into the Internet of Things with the Bosch Optiflow with Bluetooth

Bosch’s OptiFlow combustion management system utilizes a patented algorithm to modulate the appliance gas valve and fan speed to ensure optimum combustion. The gas to air ratio is measured 4 times per second, and if necessary adjusted. This process is ongoing over the lifetime of the appliance, allowing it to intelligently and continuously adapt to changing environmental conditions, ensuring optimum efficiency in all conditions over the lifetime of the appliance.

A new patented Bosch technology known as “Easy Minimum” allows the OptiFlow hot water system to operate at very low minimum power output, while maintaining a stable output temperature for more comfortable showers. This technology is beneficial in situations where the incoming water temperature is high and only a small temperate rise is needed. In this situation the appliance burner modulates in conjunction with an active by-pass valve. This feature extends the operating range of continuous flow water heater technology.


3.7914

Features

> OptiFlow combustion management system
> Bluetooth enabled appliance
> Compatible with OptiFlow App
> 6 star efficiency
> Compact, lightweight
> Solar compatible water heater
> Electronically controlled modulation
> Up to 3 controllers can be installed in addition to the Bluetooth controller
> 50°C compliant models available
> 3 year parts and labour warranty
> 12 year heat exchanger warranty (part only)


3.7914

Specifications



Bosch Optiflow specificationsContact  SA Hot Water™ for more information.


3.7914
Bosch Optiflow Professional
Bosch_Optiflow_Professional

Bosch Optiflow Professional

OptiFlow combustion management system
6 star efficiency
Compact, lightweight water heater
Solar compatible appliance
Up to 4 optional controllers
Electronically controlled modulation
3 year parts and labour warranty
12 year heat exchanger warranty (part only)
50°C compliant models available

The Bosch OptiFlow Professional is a gas-powered, 6 star energy rated continuous flow hot water system which comes in 16L, 20L and 26L varieties. The Professional model is the non-bluetooth enabled version.

Bosch’s OptiFlow combustion management system utilizes a patented algorithm to modulate the appliance gas valve and fan speed to ensure optimum combustion. The gas to air ratio is measured 4 times per second, and if necessary adjusted. This process is ongoing over the lifetime of the appliance, allowing it to intelligently and continuously adapt to changing environmental conditions, ensuring optimum efficiency in all conditions over the lifetime of the appliance.

A new patented Bosch technology known as “Easy Minimum” allows the OptiFlow hot water system to operate at very low minimum power output, while maintaining a stable output temperature for more comfortable showers. This technology is beneficial in situations where the incoming water temperature is high and only a small temperate rise is needed. In this situation the appliance burner modulates in conjunction with an active by-pass valve. This feature extends the operating range of continuous flow water heater technology.

Also available as the Optiflow Professional Internal, a room selaed appliance for indoor installation.


3.9111

Features

> OptiFlow combustion management system
> 6 star efficiency
> Compact, lightweight
> Solar compatible water heater
> Electronically controlled modulation
> Up to 4 optional controllers
> 50°C compliant models available
> 3 year parts and labour warranty
> 12 year heat exchanger warranty (part only)


3.9111

Specifications



Optiflow professional specsContact  SA Hot Water™ for more information.


3.9111
Bosch Optiflow Internal
Bosch Optiflow Internal

Bosch Optiflow Internal

OptiFlow combustion management system
Room sealed appliance
6 star efficiency
Compact, lightweight
Solar compatible water heater
Electronically controlled modulation
Up to 4 optional controllers
50°C compliant models available
3 year parts and labour warranty
12 year heat exchanger warranty

The Bosch OptiFlow Professional Internal is a room-sealed
continuous flow water heater, with fluing flexibility that
allows installation close to the point of use.

Available 12, 16 & 20 litre per minute models.

Room sealed appliance
Inbuilt temperature controller
Electronically controlled modulation
50°C locked models available
6 Star efficiency


3.7713

Features

> OptiFlow combustion management system
> Bluetooth enabled appliance
> Compatible with OptiFlow App
> 6 star efficiency
> Compact, lightweight
> Solar compatible water heater
> Electronically controlled modulation
> Up to 3 controllers can be installed in addition to the Bluetooth controller
> 50°C compliant models available
> 3 year parts and labour warranty
> 12 year heat exchanger warranty (part only)


3.7713

Specifications







Contact  SA Hot Water™ for more information.




3.7713
Bosch Highflow

Click Image for full details

  • Bosch 17e

    Bosch 17e

    Bosch 17e
    Gas Hot Water System
    1 Bathroom
    5.66 Star Energy Rating
    17 Litre Per Minute
    Flow Rate
    3 Years
    Parts & Labour Warranty
    10 Years
    Heat Exchanger Warranty
    Antifrost
    Natural Gas or LPG
    External Installation
  • Bosch 21e

    Bosch 21e

    Bosch 21e
    Gas Hot Water System
    1 to 2 Bathrooms
    5.56 Star Energy Rating
    21 Litre Per Minute
    Flow Rate
    3 Years
    Parts & Labour Warranty
    10 Years
    Heat Exchanger Warranty
    Antifrost
    Natural Gas or LPG
    External Installation
  • Bosch 26e

    Bosch 26e

    Bosch 26e
    Gas Hot Water System
    2 to 3 Bathrooms
    5.53 Star Energy Rating
    26 Litre Per Minute
    Flow Rate
    3 Years
    Parts & Labour Warranty
    10 Years
    Heat Exchanger Warranty
    Antifrost
    Natural Gas or LPG
    External Installation
  • Bosch Internal Compact Hot Water System 26eco

    Bosch 26eco+

    Bosch 26e
    Gas Hot Water System
    2 to 3 Bathrooms
    6.9-star energy efficiency rating
    26 Litre Per Minute
    Flow Rate
    3 Years
    Parts & Labour Warranty
    10 Years
    Heat Exchanger Warranty
    Antifrost
    Natural Gas or LPG
    External Installation
Bosch HighFlow Condensing

Click Image for full details

  • Bosch C21 Hot Water System

    Bosch C21

    Bosch C21
    Gas Hot Water System
    1 to 2 Bathrooms
    5.56 Star Energy Rating
    21 Litre Per Minute
    Flow Rate
    3 Years
    Parts & Labour Warranty
    10 Years
    Heat Exchanger Warranty
    Antifrost
    Natural Gas or LPG
    External Installation
  • BOSCH-C26 Hot Water System

    Bosch C26

    Bosch 26c
    Gas Hot Water System
    2 to 3 Bathrooms
    6.9 Star Energy Rating
    26 Litre Per Minute
    Flow Rate
    3 Years
    Parts & Labour Warranty
    10 Years
    Heat Exchanger Warranty
    Antifrost
    Natural Gas or LPG
    External Installation
Bosch Hydropower

Click Image for full details

  • Bosch 10H

    Bosch 10H

    Bosch Hydropower Gas Hot Water System 10H. 1 bathroom homes /single occupant.

  • Bosch 13H

    Bosch 13H

    Bosch Pilot Ignition Gas Hot Water System 13H. 1 bathroom homes /1-2 occupants.

  • Bosch 16H

    Bosch 16H

    Bosch Hydropower Gas Hot Water System 16H. 1 bathroom homes /2-3 occupants.

Bosch Pilot Range

Click Image for full details

  • Bosch10P Gas Hot Water System

    Bosch 10P

    1 bathroom homes /single occupant.
    Standing pilot light (traditional design) and operation
    Continuous flow design
    No 240 volt power required
    Designed for external installation only
    10L/minute capacity
    Attractive alternative to storage water heater when no power required



  • Bosch 13P

    Bosch 13P

    1 bathroom homes /single occupant.
    Standing pilot light (traditional design) and operation
    Continuous flow design
    No 240 volt power required
    Designed for external installation only
    13L/minute capacity
    Attractive alternative to storage water heater when no power required
  • Bosch 16P

    Bosch 16P

    1/2 bathroom homes
    Standing pilot light (traditional design) and operation
    Continuous flow design
    No 240 volt power required
    Designed for external installation only
    16L/minute capacity
    Attractive alternative to storage water heater when no power required

Bosch 10P-13P-16P hot water systems cannot be installed in South Australia  – See SA Water heater requirements –
https://sahotwater.com.au/wp-content/uploads/2012/11/Water-heater-requirements_fact-sheet_V2_revised-Feb-2014.pdf

Bosch Compact Internal

Click Image for full details

  • Bosch C10 high res

    Bosch Ci10

    Bosch Internal Compact Hot Water System Ci10. 1 bathroom homes /single occupant.

    (click image for more)

  • Bosch 32Q 2

    Bosch Ci13

    Bosch Internal Compact Hot Water System Ci13. 1 bathroom homes /single occupant.

    (click image for more)

  • Bosch C16 high res

    Bosch Ci16

    Bosch Internal Compact Hot Water System Ci10. 1-2 bathroom homes.

    (click image for more)

Bosch 32 Commercial

Click Image for full details

  • Bosch 32Q 1

    Bosch 32C

    The high efficiency solution for commercial applications utilising condensing technology.
    Secondary heat exchanger to maximise energy efficiency
    6 star efficiency
    Available in 32 L/minute capacity
    Available in natural gas and LPG variants
  • Bosch 32Q

    Bosch 32Q

    Robust solution for commercial applications
    Commercial grade components throughout
    4.8 Star energy efficiency
    Available in 32L/min capacity
    Available in natural gas and LP gas variants

Rinnai Instant Gas Hot Water

SA Hot Water™ sells the complete range of Rinnai Hot water systems at the best prices in Adelaide.

We also maintain and repair Rinnai hot water systems

The Rinnai Instant Gas range comprises:

Rinnai Builders Range
Rinnai Builders Range

Rinnai Builders Range

These units are highly energy efficient, only heating water as it passes through the unit, reducing running costs and greenhouse gas emissions substantially. Add to this its compact size which allows it to be installed almost anywhere, and you have the most technologically advanced hot water system available today.

The range is available in 16L (6.2 star), 20L (6.1 star) or 26L (6.1 star) variants supplied in a neutral Dune colour. Temperature presets of 50°C or 60°C are also available.

When installing a Rinnai continuous flow unit in a new home or renovation, consider including a recess box –allowing the pipe work, powerpoint and hot water system to be recessed into the cavity of the wall saving precious outdoor space. Rinnai has 2 types of recess boxes for our Builders Series water heaters.

Lockable Recess Box
Manufactured from sturdy aluminium with an inbuilt bracket for locking (via padlock), a Rinnai Lockable Recess Box protects the water heater from theft whilst also providing the benefits of a recessed installation. One model recess box suits B16, 20 and 26.

Smartbox® Recess Box
The Smartbox® can be installed in any application; including brick and weatherboard homes. Manufactured from tough ABS plastic material, Rinnai’s Smartbox® has been purposely designed to be light-weight, easy to handle, durable and safe to install. The box cover is supplied in a neutral Dune colour and can be painted to blend into any home colour scheme. One model recess box suits B16, 20 and 26.

Pipe Covers
Pipe Covers can be easily attached to all Rinnai continuous flow units to cover the pipes, valves and external power point as an alternative to the recess box; providing a clean and smooth finish to the installation. Two Pipe Covers can be joined together to hide longer pipe work under the unit if required.

Security Bracket
Secure your investment with Rinnai’s quick and easy to install security bracket. This simple bracket will assist in the protection of any Rinnai continuous flow model from theft when it is located in an exposed area. The bracket fits over the wall mounting bracket covering the holes where the unit is secured to the wall. A standard padlock and key is required (purchased separately).


4.333
  • Quality Japanese design and manufacturing in Rinnai’s own high tech facility
  • High quality componentry engineered to last
  • Quick connect system for temperature controller cables
  • Puretemp™ temperature stability technology provides PCB controlledand perfectly stable outlet water temperature
  • Superior 6+ star efficiency across the range of 16 – 26 litre units
  • 10 years heat exchanger warranty
  • Sleek and compact design
  • Low flow shower head compatible

4.333
Model B16 B20 B26
Bathrooms 1 1-2 2 +
Installation External External External
Gas Energy Rating 6.2 6.1 6.1
Heating Capacity L/Min (raised at 25ºC) 16 20 26
Height 530 530 530
Width 350 350 350
Depth 194 194 194
Weight 15kg 15kg 16kg
Gas Input (High) 125MJ/h 160MJ/h 199MJ/h
Cold water connection (mm) 15 (1/2”) 20 (3/4”) 20 (3/4”)
Hot Water Connection (mm) 15 (1/2”) 20 (3/4”) 20 (3/4”)
Gas Connection (mm) 20 (3/4”) 20 (3/4”) 20 (3/4”)
Minimum/Max Flow L/Min 2.4/20 2.4/24 2.4/26
Factory Pre-set Temperature (°C) 50/60 50/60 50/60
Colour Dune Dune Dune
Ignition Direct electronic ignition with automatic flame sensing
Gas Type NG / LPG
Electrical Supply AC 240V 50 Hz (10 amp weatherproof power point)
Water Controllers Up to 4 Water Controllers can be installed
Heat Exchanger Warranty* 10 years
Parts and Labour Warranty* 3 Years (5 Years if two or more Water Controllers are installed in domestic applications)

Technical Manual


4.333
Rinnai Infinity

Click image for full details

Rinnai Infinity 26 Touch

Rinnai INFINITY 26 Touch

Rinnai INFINITY 26 Touch

Using both fingertip wireless temperature control and the famous Rinnai Infinity 26 – combined they make the new Rinnai Infinity 26 Touch.

The Rinnai Infinity 26 Touch comes complete with inbuilt wireless temperature control, ready to be installed and enjoyed.

The Rinnai INFINITY 26 Touch is Ideal for two to three bathroom homes, and ensures you’ll always have enough safe and temperature controlled hot water for your household requirements.

The Rinnai INFINITY heats water as it passes through the unit, which means you are only using energy when you turn the tap on.

It is an extremely energy efficient choice as the water is only heated when required, lowering running costs and greenhouse gas emissions substantially.

Add to this the convenience of precise water and temperature control with the installation of Water Controllers and it’s compact size, which allows it to be installed almost anywhere, and you have the most technologically advanced hot water system available today in SA Hot Water™ Adelaide!



Unique Wireless Temperature Control Technology

  • Exclusive to Rinnai, the wireless technology and controller is now supplied with the unit – precise temperature control is in the palm of your hand.

6.1 Star equivalent energy rating*

  • Low running costs
  • High efficiency
  • Low greenhouse gas emissions

Superior technology

  • Quality Japanese design and manufacturing built to last
  • Precise wireless temperature control for safety and convenience
  • Compact design allows installation flexibility
  • Suitable for higher ambient water temperatures
  • Compatible with low flow rated shower fixtures (3 Star – 7.0 to 9.0 l/min)

Rinnai quality

  • After sales support network
  • 12 year warranty on heat exchanger


Dimensions (mm) : Height

503

Dimensions (mm) : Width

356

Dimensions (mm) : Depth

202

Colours

Champagne Pearl

Factory Default Temperature (Celsius)

50 or 60

Water Pressure (kPa) : Minimum

200

Water Pressure (kPa) : Maximum

1000

Gas Rate Min/Max (Mj/h) : NG

13.8/199

Flow Rate 25 Degrees C/Max : l/min

26/26

Star Rating

6.1* Equivalent

Connection Sizes Gas/Hot/Cold (mm)

20/20/20

Status Monitor

Yes

Dimensions (mm) : Height Inc Brackets

571

Dimensions (mm) : Hot Water Outlet (From Wall)

87

Dimensions (mm) : Hot Water Outlet (Left from Centre)

105

Dimensions (mm) : Cold Water Inlet (From Wall)

68

Dimensions (mm) : Cold Water Inlet (Right from Centre)

10

Dimensions (mm) : Gas Connection (From Wall)

77

Dimensions (mm) : Gas Connection (Right from Centre)

83

Dimensions (mm) : Gas Connection Length (From Base)

40

Dimensions (mm) : Cold Connection Length (From Base)

50

Weight (kg)

16



Technical Manual


Rinnai Infinity Internal

Rinnai INFINITY 26i Gas Hot Water System (Internal)

Rinnai INFINITY 26i Gas Hot Water System (Internal).

The Rinnai INFINITY 26i is a continuous flow system that’s designed specifically to be installed internally. Requiring a separately purchased flue kit, the 26i is ideal for replacing an old internal storage cylinder with today’s technology. Utilising a co-axial flue system allows the INFINITY 26i to be ‘room sealed’, meaning it can be installed almost anywhere.

The Rinnai INFINITY heats water as it passes through the unit, which means you are only using energy when you turn the tap on.

It is an extremely energy efficient choice as the water is only heated when required, lowering running costs and greenhouse gas emissions substantially.

Add to this the convenience of precise water and temperature control with the installation of Water Controllers and it’s compact size, which allows it to be installed almost anywhere, and you have the most technologically advanced hot water system available today in SA Hot Water™ Adelaide!

The Rinnai INFINITY 26i is Australia’s only 26 Litre system capable of being installed internally. Requiring separately purchased flueing, the 26i is ideal when external space is unavailable (i.e. Apartments or Townhouses) or simply for replacing an old fashioned internal Storage Cylinder with today’s technology!



5.0 Star Rating

  • Low running costs
  • High efficiency
  • Low greenhouse gas emissions

Superior Technology

  • Quality Japanese design and manufacturing
  • Precise temperature control for safety & convenience
  • Compact design allowing installation flexibility
  • Flexible Flueing options allowing installation viitually anywhere (sold seperately)
  • Suitable for higher incoming (ambient) water temperatures
  • Compatible with low flow rated shower fixtures (3 Star – 7.0 to 9.0 l/min)

Rinnai Quality

  • After sales support
  • 10 year warranty on Heat Exchanger

Rinnai Infinity 26 Smart Start

Rinnai INFINITY 26 Smartstart® Gas Hot Water System

Rinnai INFINITY 26 Smartstart® Gas Hot Water System.

Rinnai revolutionised the Australian water heating market in the early 90′s when it launched the first fully electronic gas Continuous Flow hot water system in Adelaide.

Appropriately named the Rinnai INFINITY because it never ran out of hot water, today systems are even more sophisticated ‘ designed with the environment in mind with low emission burners, high efficiencies and low flow rates compatible with water saving (WELS) outlets and showers.

The Rinnai INFINITY heats water as it passes through the unit, which means you are only using energy when you turn the tap on.

It is an extremely energy efficient choice as the water is only heated when required, lowering running costs and greenhouse gas emissions substantially.

Add to this the convenience of precise water and temperature control with the installation of Water Controllers and it’s compact size, which allows it to be installed almost anywhere, and you have the most technologically advanced hot water system available today in SA Hot Water™ Adelaide!

Introducing Australia’s first dedicated 26 Litre ‘Water Saving’ hot water system. It has all the great features of the standard Rinnai INFINITY Continuous Flow, with the addition of a circulating pump to pre-heat the water in the pipes. This may take a minute or two depending on the size of your home, but will help you save literally tens of thousands of litres of water over the life of your hot water system.


32

5.3 Star Rating

  • Low running costs
  • High efficiency
  • Low greenhouse gas emissions

Superior Technology

  • Quality Japanese design and manufacturing
  • Precise temperature control for safety & convenience
  • Compact design allowing installation flexibility
  • Suitable for higher incoming (ambient) water temperatures
  • Compatible with low flow rated shower fixtures (3 Star – 7.0 to 9.0 l/min)

Rinnai Quality

  • After sales support
  • 10 year warranty on Heat Exchanger

32
Rinnai Infinity 26 Enviro
Rinnai-Infinity-26-Enviro-7-Star-Continuous-Flow-hot-water-system

Rinnai INFINITY 26 Enviro Gas Hot Water System

Rinnai INFINITY 26 Enviro Gas Hot Water System.

Rinnai revolutionised the Australian water heating market in the early 90′s when it launched the first fully electronic gas Continuous Flow hot water system in Adelaide.

Appropriately named the Rinnai INFINITY because it never ran out of hot water, today systems are even more sophisticated ‘ designed with the environment in mind with low emission burners, high efficiencies and low flow rates compatible with water saving (WELS) outlets and showers.

The Rinnai INFINITY heats water as it passes through the unit, which means you are only using energy when you turn the tap on.

It is an extremely energy efficient choice as the water is only heated when required, lowering running costs and greenhouse gas emissions substantially.

Add to this the convenience of precise water and temperature control with the installation of Water Controllers and it’s compact size, which allows it to be installed almost anywhere, and you have the most technologically advanced hot water system available today in SA Hot Water™ Adelaide!

Australia’s Most Efficient 26L Hot Water System – lower running costs, lower environmental impact, avaible in SA Hot Water™ Adelaide.

Introducing the most energy efficient 26 Litre system on the Australian market. – the Rinnai INFINITY 26 Enviro. Technically they are known as “condensing unit”, but what is important is that they use considerably less gas to produce the same quantity of hot water as standard systems.


4.52
  • Australia’s first 7 Star equivalent 26 litre Hot Water System
  • Use less gas, substantially reducing running costs
  • Around 1/6th of the Greenhouse Emissions of a standard electric hot water
  • Also available as a 32 Litre – 6.8 Star equivalent
  • 12 year warranty on the Heat Exchanger

4.52
Rinnai Infinity 32

Rinnai INFINITY 32 Gas Hot Water System

Rinnai INFINITY 32 Gas Hot Water System.

Rinnai revolutionised the Australian water heating market in the early 90′s when it launched the first fully electronic gas Continuous Flow hot water system in Adelaide.

Appropriately named the Rinnai INFINITY because it never ran out of hot water, today systems are even more sophisticated ‘ designed with the environment in mind with low emission burners, high efficiencies and low flow rates compatible with water saving (WELS) outlets and showers.

The Rinnai INFINITY heats water as it passes through the unit, which means you are only using energy when you turn the tap on.

It is an extremely energy efficient choice as the water is only heated when required, lowering running costs and greenhouse gas emissions substantially.

Add to this the convenience of precise water and temperature control with the installation of Water Controllers and it’s compact size, which allows it to be installed almost anywhere, and you have the most technologically advanced hot water system available today in SA Hot Water™ Adelaide!

The Rinnai INFINITY 32 is designed purely for those that have large Hot Water needs such as 3+ bathroom homes. With a variable flow rate of up to a massive 37 litres per minute, the INFINITY 32 is a serious hot water unit!



5.3 Star Rating

  • Low running costs
  • High efficiency
  • Low greenhouse gas emissions

Superior Technology

  • Quality Japanese design and manufacturing
  • Precise temperature control for safety & convenience
  • Compact design allowing installation flexibility
  • Suitable for higher incoming (ambient) water temperatures
  • Compatible with low flow rated shower fixtures (3 Star – 7.0 to 9.0 l/min)

Rinnai Quality

  • After sales support
  • 10 year warranty on Heat Exchanger

Rinnai Infinity 32 Enviro
Rinnai-Infinity-32-Enviro-7-Star-Continuous-Flow-hot-water-system

Rinnai INFINITY 32 Enviro

Rinnai INFINITY 32 Enviro Gas Hot Water System.

Rinnai revolutionised the Australian water heating market in the early 90′s when it launched the first fully electronic gas Continuous Flow hot water system in Adelaide.

Appropriately named the Rinnai INFINITY because it never ran out of hot water, today systems are even more sophisticated ‘ designed with the environment in mind with low emission burners, high efficiencies and low flow rates compatible with water saving (WELS) outlets and showers.

The Rinnai INFINITY heats water as it passes through the unit, which means you are only using energy when you turn the tap on.

Lower running costs. Lower environmental impact.

One of the most energy efficient systems on the Australian market, the Rinnai INFINITY 32 Enviro uses considerably less gas to produce the same quantity of hot water as a standard system. This highly efficient system uses heat from its exhaust to pre-heat the water before it enters the heat exchanger.


  • 7.0 Star equivalent* 32 litre hot water system
  • Inbuilt Energy Recovery System (Condensing Technology)
  • Uses less gas, substantially reducing running costs
  • Generates only 1/6th of the greenhouse gas emissions of a standard electric hot water system
  • Also available as a 26 Litre – 7.0 Star equivalent*
  • 12 year warranty on the heat exchanger


Dimensions (mm) : Height

670

Dimensions (mm) : Width

470

Dimensions (mm) : Depth

283

Colours

Titanium

Factory Default Temperature (Celsius)

60

Water Pressure (kPa) : Minimum

220

Water Pressure (kPa) : Maximum

1000

Gas Rate Min/Max (Mj/h) : NG

10/211

Flow Rate 25 Degrees C/Max : l/min

32/37

Star Rating

7.0* Equivalent

Connection Sizes Gas/Hot/Cold (mm)

20/20/20

Status Monitor

Yes

Dimensions (mm) : Height Inc Brackets

722

Dimensions (mm) : Hot Water Outlet (From Wall)

115

Dimensions (mm) : Hot Water Outlet (Left from Centre)

100

Dimensions (mm) : Cold Water Inlet (From Wall)

80

Dimensions (mm) : Cold Water Inlet (Right from Centre)

28

Dimensions (mm) : Gas Connection (From Wall)

104

Dimensions (mm) : Gas Connection (Right from Centre)

103

Dimensions (mm) : Condensate Outlet (From Wall)

138

Dimensions (mm) : Condensate Outlet (From Centre)

195

Dimensions (mm) : Gas Connection Length (From Base)

40

Dimensions (mm) : Cold Connection Length (From Base)

50

Dimensions (mm) : Condensate Connection (From Base)

22

Dimensions (mm) : Condensate Fitting Diameter

15

Weight (kg)

32

Hot Connection Length (from base)

41

Operation & Installation Manual

Parts Manual

Product Range Guide


Rinnai Hotflo 10
Rinnai hotflo10

Rinnai Hotflo 10

Rinnai Hotflo 10

Rinnai revolutionised the Australian water heating market in the early 90′s when it launched the first fully electronic gas Continuous Flow hot water system in Adelaide.

Appropriately named the Rinnai INFINITY because it never ran out of hot water, today systems are even more sophisticated ‘ designed with the environment in mind with low emission burners, high efficiencies and low flow rates compatible with water saving (WELS) outlets and showers.

The Rinnai INFINITY heats water as it passes through the unit, which means you are only using energy when you turn the tap on.

Ideal for applications with no power available or where there is a minimal requirement for hot water, Rinnai are proud to introduce the Hotflo 10.

The Hotflo 10 features unique Puretemp™ temperature stability technology – eliminating hot and cold temperature fluctuations common in older generation hot water systems.


44

5.5 Star Rating

  • Low running costs
  • High efficiency
  • Low greenhouse gas emissions

Superior Technology

  • Quality Japanese design and manufacturing
  • Precise temperature control for safety & convenience
  • Compact design allowing installation flexibility
  • Suitable for higher incoming (ambient) water temperatures
  • Compatible with low flow rated shower fixtures (3 Star – 7.0 to 9.0 l/min)

Rinnai Quality

  • After sales support
  • 10 year warranty on Heat Exchanger

44

Aquamax Instant Gas Hot Water

Aquamax Instant Gas Hot Water
Aquamax-Gas-26L

AquaMAX Instant Gas Hot Water

AquaMAX 20& 26 Instant Gas Hot Water Systems

The AquaMAX instant gas hot water heaters offer flexible hot water delivery to any family, big or small. The 26L model delivers a higher flow rate for larger families.

Available in SA Hot Water™ Adelaide the AquaMAX gas hot water systems are tough enough for even the most demanding of households.

With compact external installation, 6 star energy efficiency and a 10 year Heat Exchanger warranty3 the AquaMAX 20 and 26 are perfect for modern Australian living. Great for households with less hot water demand as water is heated only when needed rather than storing heated water. A plumber’s inspection is advised before fitting as gas piping requirements may vary from property to property.


52
  • 20L or 26L per minute flow rate (at 25°C rise)
  • Natural or LPG Gas
  • 6.0 Star Energy Rating
  • Optional temperature controller
  • 10 Year Heat Exchanger warranty3

52

Product Brochure

Specifications AquaMAX 20
Number of Bathrooms 1.5-2
Gas Type Natural/LPG
Gas Energy Rating 6.0 Stars
Flow Rate L/min at 25ºC rise 20 L/min
Minimum Operating Flow Rate 2.5 L/min
Nominal Gas Consumption 153 MJ/Hr
Preset Temperature Options 50oC or 60oC
Watermark licence No. WMKA21434
AGA Certificate No. 7306



Specifications AquaMAX 26
Number of Bathrooms 2-2.5
Gas Type Natural/LPG
Gas Energy Rating 5.9 Stars
Flow Rate L/min at 25ºC rise 26 L/min
Minimum Operating Flow Rate 3.0 L/min
Nominal Gas Consumption 199 MJ/Hr
Preset Temperature Options 500C or 600C
Watermark licence No. WMKA00519
AGA Certificate No. 6004

52

Dux Instant Gas Hot Water Systems

SA Hot Water™ sells the complete range of Dux Hot water systems at the best prices in Adelaide.

We also supply the a large range of Dux Spare Parts

Dux manufacture the following types of instant gas systems:

Dux Condensing

Dux Condensing Instant Gas

Dux Condensing Instant Gas 21L & 26L models

Compact and efficient, Dux’s latest range of Continuous Flow units are an excellent option for Australian homes. Dux gas continuous flow water heaters heat the water only as needed, not wasting energy by keeping water in a tank hot, earning it a 6 star (or higher) energy rating.

  • Condensing delivers over $1000# savings over the 12 year warranty of the heat exchanger
  • Providing Australian homes with superior technology straight from Noritz, Japan’s leading manufacturer of household water heaters
  • Features superior condensing technology that boasts over 90% thermal efficiency by capturing additional heat in the secondary heat exchanger
  • Smallest domestic condensing gas water heater
  • No standby pilot light
  • 6 star or higher energy rating
  • 12-year warranty on heat exchanger, including 3-year full parts and labour*

SA Hot Water™ has available a big range of Dux Hot Water Systems in Adelaide.


53
  • Heats water as required resulting in reduced running costs and lower gas bills
  • Never run out of hot water
  • Superior condensing technology that boasts over 90% thermal efficiency
  • 6.7 star rating
  • Smallest domestic condensing gas water heater
  • Corrosion resistant secondary heat exchanger
  • 12 year warranty on heat exchanger and 3 years on parts and labour

53

Specifications manual

Condensing Continuous Flow 21L
Model Number: 21ECB
Tank Size: 21L/min
Specifications
Star Rating: 6.7
Hot water capacity: 21L/min @ 25oC rise
Min water flow: 2.4 litres/minute
Dimensions (mm): Height: 520
Width: 350
Depth: 170
Weight: 17kg
Available in 50oC and 60oC model options:
21ECB5N – 21L/min Nat Gas  50 deg
21ECB6N – 21L/min Nat Gas  60 deg
21ECB5L – 21L/min LPG  50 deg
21ECB6L – 21L/min LPG  60 deg



Condensing Continuous Flow 26L
Model Number: 26ECB
Specifications
Star Rating: 6.7
Hot water capacity: 26L/min @ 25oC rise
Min water flow: 2.4 litres/minute
Dimensions (mm): Height: 520
Width: 350
Depth: 170
Weight: 18kg
Available in 50oc and 60oc model options:
26ECB5N – 26L/min Nat Gas  50 deg
26ECB6N – 26L/min Nat Gas  60 deg
26ECB5L – 26L/min LPG  50 deg
26ECB6L – 26L/min LPG  60 deg

53
Dux Non Condensing

Dux Non Condensing Instant Gas

Dux Non-Condensing Instant Gas 17L, 21L & 26L models for different household sizes.

Compact and efficient, Dux’s latest range of Continuous Flow units are an excellent option for Australian homes. Dux gas continuous flow water heaters heat the water only as needed, not wasting energy by keeping water in a tank hot, earning it a 6 star (or higher) energy rating.

  • Providing Australian homes with superior technology straight from Noritz, Japan’s leading manufacturer of household water heaters
  • Features superior condensing technology that boasts over 90% thermal efficiency by capturing additional heat in the secondary heat exchanger
  • No standby pilot light
  • 6 star or higher energy rating
  • 12-year warranty on heat exchanger, including 3-year full parts and labour*

SA Hot Water™ has available a big range of Dux Hot Water Systems in Adelaide.




51
  • Heats water as required resulting in reduced running costs and lower gas bills
  • Never run out of hot water
  • 6 star rating, or higher
  • Compact design
  • 12 year warranty on heat exchanger and 3 years on parts and labour

51

Specifications manual

Non-Condensing Continuous Flow 17L
Model Number: 17ENB
Tank Size: 17L/min
Specifications
Star Rating: 6
Hot water capacity: 17L/min @ 25oC rise
Min water flow: 2.4 litres/minute
Dimensions (mm): Height: 520
Width: 350
Depth: 170
Weight: 14kg
Available in 50oC and 60oC model options:
17ENB5N- 21L/min Nat Gas  50 deg
17ENB6N- 21L/min Nat Gas  60 deg
17ENB5L- 21L/min LPG  50 deg
17ENB6L- 21L/min LPG  60 deg



Non-Condensing Continuous Flow 21L
Model Number: 21ENB
Tank Size: 21L/min
Specifications
Star Rating: 6.1
Hot water capacity: 21L/min @ 25oC rise
Min water flow: 2.4 litres/minute
Dimensions (mm): Height: 520
Width: 350
Depth: 170
Weight: 15kg
Available in 50oC and 60oC model options:
21ENB5N- 21L/min Nat Gas  50 deg
21ENB6N- 21L/min Nat Gas  60 deg
21ENB5L- 21L/min LPG  50 deg
21ENB6L- 21L/min LPG  60 deg



Non-Condensing Continuous Flow 26L (26L/min)
Model Number: 26ENA
Tank Size: 26L/min
Specifications
Star Rating: 6
Hot water capacity: 26L/min @ 25oC rise
Min water flow: 2.4 litres/minute
Dimensions (mm): Height: 600
Width: 350
Depth: 170
Weight: 22kg
Available in 50oC and 60oC model options:
26ENA5N- 26L/min Nat Gas  50 deg
26ENA6N- 26L/min Nat Gas  60 deg
26ENA5L- 26L/min LPG  50 deg
26ENA6L- 26L/min LPG  60 deg

51
Condensing or Non-Condensing?
condensing-or-not

Rheem Instant Gas Hot Water Systems

SA Hot Water™ sells the complete range of Rheem Hot water systems at the best prices in Adelaide.

We also supply the a large range of Rheem Spare Parts

Rheem manufacture the following types of instant gas systems:

Rheem Integrity
Rheem Integrity 20

Rheem Integrity

The Integrity series is available in 12l, 20l and 24l sizes to cover all home sizes and number of occupants.

12 litre per minute for apartments/single occupier homes

20l litre per minute for 2-3 person homes

24 litre per minute for 4+ person homes

YOU’LL BE RIGHT WITH RHEEM
No.1 with Australian families. Rheem is Australia’s favourite hot water system… and it’s been that way since 1939, when Rheem started making hot water heaters in Australia. Three generations of Australian families have relied on Rheem for water that is steady, hot and strong!

The Integrity series is available in 12l, 20l and 24l sizes to cover all home sizes and number of occupants.

12 litre per minute for apartments/single occupier homes

20l litre per minute for 2-3 person homes

24 litre per minute for 4+ person homes


47
  • 12l/20L/24l min hot water delivery (at 25°C rise)
  • Flamesafe® overheat protection — shuts down your heater before overheating can occur.
  • Remote temperature controller options — so you can set the best and safest temperature for different taps around the home.
  • Rheem Q Factor™ — ensures rapid hot water every time, with none of the fluctuations that occur with some continuous flow units.
  • Extra safety — 50°C temperature limited models available. 10 year warranty on heat exchanger*.

Warranty:

  • 10 year parts & 3 years labour on heat exchanger*.
  • 3 year parts & labour warranty on all other components, for domestic (Non-commercial) installations only*

47
Rheem Metro

Rheem Metro

Rheem Metro Series guarantees you hot water that never runs out, with quality and performance to add value and peace of mind to your home.

  • 10 Years parts and 3 Years labour on Heat Exchanger
  • 3 Years parts & labour on other components, when installed in a domestic dwelling.
  • For all other installations, the warranty period is 1 Year parts and labour on Heat Exchanger and other components



Rheem Metro Series guarantees you hot water that never runs out, with quality and performance to add value and peace of mind to your home.

The Metro series is available in 16l, 24l and 26l sizes to cover all home sizes and number of occupants.


4.138

Both 60ºC and 50ºC models:

• 60ºC hot water for kitchen and laundry
– where 50 or 55ºC is often not hot enough

• 50ºC models provide the added safety
of a fully-tempered home at 50ºC (without
the cost of a tempering valve)

• Remote Temperature Controller options
for added convenience and safety

• Digital display for easy fault diagnosis
and service

• 10 Year Heat Exchanger Warranty¹

• 50°C models available – adjustable to deliver
50°C at the nearest tap.

• Flamesafe® overheat protection – shuts down
the heater before overheating can occur

• Rheem Q Factor – hot water every time, without
fluctuation when multiple taps demand hot water

• Wall Mount Security Bracket available – for added
water heater security (refer to illustration overleaf)

• Natural Gas or Propane

• Frost protected down to -20°C


4.138

Specifications

Owners Guide

Model Number 876E16
874E16
875E24
871E24
875E26
871E26
Pre-set Temperature ˚C 50       60 50       60 50      60
Number of Bathrooms 1 – 1.5 2 – 2.5 2 – 3
Gas Type Natural Gas/ Propane Natural Gas/ Propane Natural Gas/ Propane
Gas Energy Rating Stars 6 6 6
Flow Rate @ 25˚C Rise L/min 16 24 26
Min. Operating Flow Rate L/min 2.7 2.7 2.7
Nominal Gas Consumption       MJ/hr 126 188 199
Dimensions
Height A mm 520 565 565
Width B mm 350 350 350
Depth C mm 160 205 205
Weight (empty) kg 18 21 21
Max. Water Supply Pressure kPa 1000 1000 1000
Min. Water Supply Pressure kPa 140 140 140
Cold Water Connection R ¾/20 R ¾/20 R ¾/20
Hot Water Connection R ¾/20 R ¾/20 R ¾/20
Gas Connection R ¾/20 R ¾/20 R ¾/20
Accessories
Pipe Cover 299841 299848 299848
Recess Box 299842 299842 299842
Wall Mount Security Kit 299868 299868
Security Cage 299867 299867 299867

4.138
Rheem Pronto
Rheem Pronto

Rheem Pronto

Rheem Pronto® instantaneous water heaters deliver category-leading performance. Along with 6 Star energy efficiency, Pronto also features an inbuilt hydro-electric generator that lights the gas as soon as the hot water tap is turned on – so no electrical connection is required.

The Pronto series is available in 12l and 16litre sizes to cover small and medium sized households.

YOU’LL BE RIGHT WITH RHEEM
No.1 with Australian families. Rheem is Australia’s favourite hot water system… and it’s been that way since 1939, when Rheem started making hot water heaters in Australia. Three generations of Australian families have relied on Rheem for water that is steady, hot and strong!

The Pronto series is available in 12l and 16litre sizes to cover small and medium sized households.

The heater’s LED monitor identifies any faults for easy analysis and servicing. And unlike some instantaneous water heaters, there are no batteries to be replaced on a regular basis.

INSTALLATION IS EASY AND FAST
Rheem Pronto uses the same mounting points as the most common mechanical water heaters. Once in place, all the fittings are also in an identical position, so no need to adjust the pipe work either.




47
  • Rheem Pronto uses the same mounting points & connections as the most common mechanical water heaters.
  • No electrical connection required
  • Electronic Temperature Control

Warranty:

  • 10 year parts & 3 years labour on heat exchanger*.
  • 3 year parts & labour warranty on all other components, for domestic (non-commercial) installations only*.

*Warranty conditions apply.


47

Takagi Instant Gas Hot Water Systems

SA Hot Water™ sells the complete range of Takagi water systems at the best prices in Adelaide.

We also supply the a large range of Takagi Spare Parts

Takagi manufacture the following 2 instant gas systems:

Takagi Instant Gas

Click Image for full details


4.7818
